Readymesh PF

Monofilament stranded macro-fibre structural for industrial flooring

Readymesh PF is a stranded structural polyolefin macro-fibre, high-performance, specific for the realisation of continuous surfaces made of concrete, it can also be used in replacement of traditional steel reinforcement. The texture, length and surface finishing of Readymesh PF was designed and developed specifically for "exposed" applications, such as industrial floors made of concrete. Readymesh PF are available in two different lengths: Readymesh PF-180 = 18 mm; Readymesh PF-540 = 54 mm
Components
Single-component
Appearance
Twisted fibers
Customs code
5404 1200

Request product info

    By submitting I agree to the privacy notice

    Obtained Certifications and Regulations
    EN 14889-2:2006 (System 1)
    Lines of belonging
    Linea prodotto Building
    Linea prodotto Floor
    Thematic site
    Readymesh
    Features and benefits
    Where it is used
    How to use
    Technical data
    Additional content
    Warnings and precautions
    Media
    Related products

    Readymesh PF

    The addition of Readymesh PF to the mixture gives the concrete and the resulting manufacture a greater resistance to the forces of traction/bending, reduces the risk of breakage and "spalling" of the concrete component in the corners and edges, drastically reduces the phenomenon of cracks due to shrinkage during the first hours of curing of the concrete.

    The particular shape and consistency, allows Readymesh PF not to interfere with the process of mechanical floating typical of industrial floors made of concrete, thus allowing a good surface finish. In addition, the use of Readymesh PF instead of the traditional armour of steel is a great saving of costs of material and installation times (in addition to being lighter, environmentally friendly and safe than electrowelded mesh).

    Fields of application
    Industrial flooring, also in replacement of steel mesh. Prefabrication. Widespread three-dimensional high anisotropy reinforcement of concretes in general.
    Allowed supports
    Concrete
    Mode of use
    Add the fibres to the concrete during mixing. Mix, with the drum of the mixer truck at full speed, for at least one minute for each mยณ of concrete. The dosage, depending on the use, is normally included between 1 to 6 kg/mยณ In the case of industrial flooring.
    Application methods
    To be added to other components
    Key features
    Density
    Density: 0.91 g/cmยณ
    Nonflammable
    Nonflammable
    Unlimited shelf-life
    Unlimited shelf-life
    UV-resistant
    UV-resistant
    Technical specifications

    Breaking load longitudinal

    516.9 MPa

    Auto-ignition temperature

    >400 ยฐC
    Resistant to chemical agents

    Flash-point
    ASTM D 1929

    350 ยฐC

    Melting temperature

    160 - 170 ยฐC
    Alkali-resistant material

    0.48 mm

    Young modulus

    5.37 GPa
    Consumption
    Variable according to the performance to be achieved in the industrial flooring to be built (on average 1 to 2 kg for each cubic metre of concrete).
    Available colors
    White
    Packaging and dimensions
    Pallet: 42 x (Box 10 Kg)
    Hydro degradable bag 1 kg
    PF-540 Box: 10 x (Hydro degradable bag 1 kg)
    Small bag 5 kg
    PF-180 Box: 7 x (Hydro degradable bag 1 kg)
    Storage and conservation
    Store the product in its original packing, in a fresh and dry environment, avoiding frost and direct sunlight.
    Additional content

    Bending test Readymesh PF-540 (RILEM TC 162-TDF)

    Dosage of fibres

    6.0 Kg/m³

    fCT,L

    3.425 MPa

    fR,1

    2.913 MPa

    fR,2

    2.660 MPa

    fR,3

    2.669 MPa

    fR,4

    2.594 MPa



    Warnings
    The general information, along with any instructions and recommendations for use of this product, including in this data sheet and eventually provided verbally or in writing, correspond to the present state of our scientific and practical knowledge.
    Any technical and performance data reported is the result of laboratory tests conducted in a controlled environment and thus may be subject to modification in relation to the actual conditions of implementation.

    Azichem Srl does not assume any liability arising from inadequate characteristics related to improper use of the product or connected to defects arising from factors or elements unrelated to the quality of the product, including improper storage.
    Those wishing to utilise the product are required to determine prior to use whether or not the same is suitable for the intended use, assuming all consequent responsibility.

    The technical and characteristic details contained in this data sheet shall be updated periodically. For consultation in real time, please visit the website: www.azichem.com. The date of revision is indicated in the space to the side. The current edition cancels out and replaces any previous version.

    Please note that the user is required to read the latest Safety Data Sheet for this product, containing chemical-physical and toxicological data, risk phrases and other information regarding the safe transport, use and disposal of the product and its packaging. For consultation, please visit: www.azichem.com.
    It is forbidden to dispose of the product and/or packaging in the environment.
