Repar Tix G2

Thixotropic slightly expansionary mortar, for anchoring and underpinning

Thixotropic, reinforced fibre, anti-shrink mortar, slightly expansive in plastic phase, high-performance in terms of resistance and waterproofing characteristics, specific for the compensation of cavities and detachments in roughcast underpinning, and for accurate fixing of wooden or steel beams in masonry whatever its nature.
Components
Single-component
Appearance
Powder
Customs code
3824 5090

Request product info

    By submitting I agree to the privacy notice

    Lines of belonging
    Linea prodotto Aqua
    Linea prodotto Infratech
    Thematic site
    Concrete Repar
    Features and benefits
    Where it is used
    How to use
    Technical data
    Additional content
    Warnings and precautions
    Media
    Related products

    Repar Tix G2

    Repar Tix G2 is based on high-resistance cements, superpozzolanic fillers, plasticisers, stabilisers, and anticorrosive agents, antiallergic additives, selected aggregates. Free of chloride, aluminium, metal powders and aggressive substances in general.
    Fields of application
    Fixing and anchorages of I-beams, clamps, beams, metal structures, reinforcing rods, prefabricated elements etc. Execution of render underpinning, in civilian, industrial, rural and infrastructural building, both for restructuring and newly built.
    Allowed supports
    Concrete
    Prefabricated concrete
    Bricks
    Mixed walls (bricks and stones)
    Stone walls
    Preparation of supports
    Application surfaces should be clean, free of soiling, crumbling and non-adhering parts, dust, etc., conveniently saturated with water until they reach the condition "saturated with dry surface". An adequate roughening of the surfaces by scarifying, sandblasting etc. is always necessary in order to obtain the maximum adhesion values to the substrate. The optimal values are obtained with high pressure hydro-scarification. Bare the irons undergoing disruptive oxidation or deeply oxidized, removing the rust of the exposed irons (by sandblasting or abrasive brushes).
    Mode of use
    Pour about 2/3 of the mixing water into the mixer, add Repar Tix G2 and the remaining water; continue to mix until a homogeneous lump-free mixture is obtained. The mixing water should be about 12-13% of the weight of the bag. After mixing is completed wait a few minutes before applying.

    For high anchoring sections add Ghiaietto 6.10 (please refer to the appropriate technical data sheet for more information).

    Application methods
    Brick trowel
    Finishing trowel
    Spatula
    Tool cleaning
    Water
    Key features
    Max. recommended thickness
    Max. recommended thickness: 8 cm
    Maximum diameter of aggregate
    Maximum diameter of aggregate: 2 mm
    Min. recommended thickness
    Min. recommended thickness: 1 cm
    Mix with water
    Mix with water: 12-13 %
    Nonflammable
    Nonflammable
    Pot-life
    Pot-life: 60 min
    Shelf-life
    Shelf-life: 12 months
    Temperature of use
    Temperature of use: +5 / +35 ยฐC
    Use wearing protective gloves
    Use wearing protective gloves
    Technical specifications

    Compressive strength after 1 day
    UNI EN 1015-11

    30 N/mmยฒ

    Compressive strength after 28 days
    UNI EN 1015-11

    60 N/mmยฒ

    Flexural strength at 1 day
    UNI EN 1015-11

    6 N/mmยฒ

    Flexural strength after 28 days
    UNI EN 1015-11

    9 N/mmยฒ

    Darcy impermeability

    10โปโน cm/s

    Contrasted expansion with air curing for 1 day
    UNI 8147

    > 0.6 mm/m

    Bonding force
    EN 1542

    > 2 MPa

    Static elastic modulus
    EN 13142

    25.000 N/mmยฒ

    Determination of thermal compatibility
    UNI EN 13687-1

    > 2 MPa

    Capillary absorption
    UNI EN 13057

    0.45 kgโ€ขh^0.5/mยฒ

    Density
    UNI EN 1015-6

    2100 kg/mยณ

    pH

    >12

    Chloride content
    UNI EN 1015-17

    < 0.01 %
    Consumption
    Approximately 19 kg/mยฒ of Repar Tix G2 for every centimetre of thickness to be implemented (approximately 1900 kg per cubic metre).
    Available colors
    Gray
    Packaging and dimensions
    Bag 25 kg
    Pallet: 50 x (Bag 25 kg)
    Storage and conservation
    Store the product in its original packing, in a fresh and dry environment, avoiding frost and direct sunlight.
    Additional content

    Warnings
    Adopt laying procedures capable of ensuring the absence of gaps and discontinuities; cure the protection and the prolonged moist hardening of exposed surfaces.The general information, along with any instructions and recommendations for use of this product, including in this data sheet and eventually provided verbally or in writing, correspond to the present state of our scientific and practical knowledge.
    Any technical and performance data reported is the result of laboratory tests conducted in a controlled environment and thus may be subject to modification in relation to the actual conditions of implementation.

    Azichem Srl does not assume any liability arising from inadequate characteristics related to improper use of the product or connected to defects arising from factors or elements unrelated to the quality of the product, including improper storage.
    Those wishing to utilise the product are required to determine prior to use whether or not the same is suitable for the intended use, assuming all consequent responsibility.

    The technical and characteristic details contained in this data sheet shall be updated periodically. For consultation in real time, please visit the website: www.azichem.com. The date of revision is indicated in the space to the side. The current edition cancels out and replaces any previous version.

    Please note that the user is required to read the latest Safety Data Sheet for this product, containing chemical-physical and toxicological data, risk phrases and other information regarding the safe transport, use and disposal of the product and its packaging. For consultation, please visit: www.azichem.com.
    It is forbidden to dispose of the product and/or packaging in the environment.
