Fields of application
Armaglass Intotech 225 is a mesh used for the reinforcement of high thickness plasters and screeds, with a uniform absorption and redistribution function of mechanical stresses and shrinkage stresses. The mesh therefore performs an important anti-cracking function on plasters and screeds. It is the ideal plaster base for our products based on natural hydraulic lime: Sanatigh, Sanawarme, Caleosana, Sanascreed and for osmotic thickening waterproofing products Osmocem MR and Osmocem RD.
Allowed supports
Concrete
Cement-based or lime-based mortars
Prefabricated concrete
Drywall
Mixed walls (bricks and stones)
Brickworks
Stone walls
Porphyry and natural stones
Preparation of supports
To prepare the substrate, carefully follow what is indicated in the technical data sheets of the product with which the Armaglass Intotech 225 mesh is combined. To facilitate collaboration with the support, Armaglass Intotech 225 can be coupled and is perfectly compatible with any type of connector (in fiberglass, resin or metal).
Mode of use
Application on masonry:
If the use of connectors is envisaged, proceed with the creation of holes of suitable diameter, depending on the selected connection system, arranged according to the design indications. Fix the connectors with anchoring resin (Syntech Profix or alternatively SYNTECH EPOXY 21) or grout based on hydraulic binders (Grout Cable or alternatively Sanafluens). Apply a first layer of mortar (see technical data sheet of the chosen product), lay the Armaglass Intotech 225 mesh on the still fresh mortar, taking care to guarantee at least 10 cm on the overlaps, lay the second layer of mortar.
Application on screeds:
Apply a first layer of screed (see technical data sheet of the chosen product), lay the Armaglass Intotech 225 mesh partially drowning it on the first layer of still fresh screed, taking care to guarantee at least 10 cm on the overlaps, laying the second layer of screed.
Application methods
To be added to other components
Technical specifications
Loss of calcination
UNI 8532
20 - 25 %
Warp tensile strength
UNI 9311-5
4000 N/5cm
Dressed fabric weight
UNI 9311-4
225 g/m²
Number of warp threads
UNI 9311-5
40
Longitudinal elongation at break
UNI 9311-5
3.20 %
Raw fabric weight
UNI 9311-4
210 g/m²
Number of weft threads
UNI 9311-5
40
Weft tensile strength
UNI 9311-5
2500 N/5cm
Consumption
1.1 m / m²: The adjacent sheets of fiberglass mesh must be overlapped along the edges by at least 10 cm.
Storage and conservation
Store the product in its original packing, in a fresh and dry environment, avoiding frost and direct sunlight.
Warnings
The general information, along with any instructions and recommendations for use of this product, including in this data sheet and eventually provided verbally or in writing, correspond to the present state of our scientific and practical knowledge.
Any technical and performance data reported is the result of laboratory tests conducted in a controlled environment and thus may be subject to modification in relation to the actual conditions of implementation.
Azichem Srl does not assume any liability arising from inadequate characteristics related to improper use of the product or connected to defects arising from factors or elements unrelated to the quality of the product, including improper storage.
Those wishing to utilise the product are required to determine prior to use whether or not the same is suitable for the intended use, assuming all consequent responsibility.
The technical and characteristic details contained in this data sheet shall be updated periodically. For consultation in real time, please visit the website: www.azichem.com. The date of revision is indicated in the space to the side. The current edition cancels out and replaces any previous version.
Please note that the user is required to read the latest Safety Data Sheet for this product, containing chemical-physical and toxicological data, risk phrases and other information regarding the safe transport, use and disposal of the product and its packaging. For consultation, please visit: www.azichem.com.
It is forbidden to dispose of the product and/or packaging in the environment.
